Features of Series 7 Bench Fume Hood
A: The viewing window is made of 5mm tempered glass, which does not shatter and splash when broken, ensuring personal safety.
B: The top lampshade serves as an explosion pressure relief device.
C: The air collecting hood is equipped with a condensed water collection device, which directly discharges condensed liquid in pipelines into the wastewater system.
D: Fitted with double mechanical anti-falling locking mechanism for the viewing window. If the transmission on one or both sides breaks, the window falling distance ≤50mm.
E: Adopts toothed synchronous belt transmission, enabling smooth, low-noise window sliding. Steel cables are wrapped inside synchronous belts for effective corrosion resistance.
F: Adopts advanced air flow layout and diversion design, with average exhaust surface wind speed of 0.3m/s and leakage rate within 0.01ppm.
G: Exhaust air volume reaches 700–850m³/h when the sash is at normal operating height, saving 40% operating energy consumption compared with fume hoods designed with 0.5m/s surface wind speed.
H: Optional pipeline fire safety detection system and gas concentration monitoring & treatment system are available.
I: The lower cabinet features negative pressure exhaust, suitable for storing common reagents and eliminating peculiar smell from volatile gases.
J: Locked fireproof cabinets can be installed in the lower cabinet to store small quantities of flammable, combustible and corrosive chemicals and reagents.
Features of Series 7 Floor-Standing Fume Hood
A: The viewing window adopts 5mm tempered glass, which will not splash when broken to protect personal safety.
B: The top lampshade integrates explosion pressure relief function.
C: The air collecting hood is equipped with a condensed water collection device, which directly drains condensed liquid in pipelines into the wastewater system.
D: Equipped with double mechanical anti-falling locking mechanism for viewing window. If the transmission device on one or both sides breaks, the falling distance of the window ≤50mm.
E: Adopts toothed synchronous belt transmission. The window slides smoothly with low noise. Steel cables are wrapped by synchronous belts to resist corrosion effectively.
F: The product can be optionally equipped with pipeline fire safety detection system and concentration detection & treatment system.
Features of Series 7 Air-supplied Fume Hood
A: The air-supplied fume hood forms a stable air curtain barrier at the front of the work surface. The supplementary air volume accounts for 50% of exhaust air volume. Under normal operation, indoor exhaust air volume is only 350–400m³/h, achieving energy saving while meeting leakage rate standards.
B: The viewing window is made of 5mm tempered glass, which will not splash when broken, protecting personal safety.
C: The top lampshade has explosion pressure relief function.
D: The air collecting hood is equipped with a condensed water collection device, which directly discharges condensed liquid in pipelines into the wastewater system.
E: Equipped with double mechanical anti-falling locking mechanism for viewing window. If the transmission device on one or both sides breaks, the falling distance of the window ≤50mm.
F: Adopts toothed synchronous belt transmission, making window sliding lightweight and low-noise. Steel cables are wrapped by synchronous belts to effectively prevent corrosion.
G: With advanced airflow layout and diversion design, the average exhaust surface wind speed is 0.3m/s, and the leakage rate is within 0.01ppm.
H: When the sash is at normal working height, the exhaust air volume is 700–850m³/h, saving 40% operating energy consumption compared with ordinary fume hoods with designed surface wind speed of 0.5m/s.
I: The product can be optionally equipped with pipeline fire safety detection system and concentration detection & treatment system.
J: The lower cabinet has negative pressure exhaust function, which can store common reagents and prevent peculiar smell caused by volatile gases.
K: The lower cabinet can be optionally fitted with locked fireproof cabinets for storing a small amount of flammable, combustible and corrosive chemicals and reagents.
